EATON WEATHERHEAD
H03916
SKU H03916

1" H039 Suction, 50 ft, Hydraulic Hose - H03916

UPC:
40142020

California Residents: Prop 65 Warning
WARNING: Cancer and Reproductive Harm
www.p65warnings.ca.gov

Pkg Qty: 50 FT

  • Temperature range -40 deg. C to +135 deg. C (-40 Deg. F to +275 deg. F)
  • Helical cable wire between two textile layers
  • Fiber braid reinforcement
  • Neoprene cover materia
  • 25 Hg vacuum service
  • CPE inner tube material
  • Compatible with S series, U series, 430 U series and Z series c-o-c fittings
  • SAE 100R4, 1/2 SAE Bend Radius
Type Hydraulic Hose
Style H039 Suction
Size 1"
Material Nitrile/Neoprene
I.D. 1"
Color Black
Hose O.D. 1-1/2"
Dash Size -16
Burst Pressure 980 PSI
Max Working Temp F 275
Working Pressure 245 PSI
Certifications SAE 100R4|ABS|SAE J1942/1
Compliances MSHA Approved
Manufacture Part # H03916
