- Available in several sizes and length configurations
- Ideal for use in high pressure lines on off road construction equipment, farm equipment, and other high pressure applications were a small bend radius is needed
- SAE 100R17
| Type | Hydraulic Hose |
| Style | H145 |
| Size | 1" |
| Material | Nitrile/Neoprene |
| I.D. | 1" |
| O.D. | 1-15/32" |
| Color | Black |
| Inner Tube | Nitrile |
| Outer Cover | Neoprene |
| Dash Size | -16 |
| Recommended Fitting Types | Z' Series, 'S' Series(except -04 and -10), 'U' Series (-6 thru -12), 'U' Series (-16 only) |
| Burst Pressure | 12180 PSI |
| Max Working Temp F | 250 |
| Working Pressure | 3045 PSI |
| Temp. Range | 4-8 Size: -40° C to +121° C (-40° F to +250° F) 10-16 Size: -40° C to +100° C (-40° F to +212° F) |
| Certifications | SAE 100R17|SAE J1942/1-Hydraulic only |
| Compliances | MSHA Approved |
| Manufacture Part # | H14516-250R |
