- Plasti-Grip Ring Terminals consist of precision formed metal wire barrel insulated with vinyl to provide maximum protection against abrasion
- Plasti-Grip terminals have a maximum operating temperature of 105° C (221°F)
| Type | Plasti-Grip |
| Style | Fork |
| AWG | 22-18 |
| Color | Red |
| Voltage | 600 VAC |
| Finish | Tin |
| Material | Copper |
| Stud Size | #8 |
| Temp Range | 90° C |
| Barrel Type | Closed |
| Length | 0.92 |
| Width | 0.375 |
| Throat Length | 0.312 |
| Effective Length | 0.728 |
| Material Thickness | 0.033 |
| Max Wire Insulation Dia. | 0.14 |
| Specifications | UL,CSA |
