- 1 million impulse cycle performanceHigher pressure ratings than standard one wire braided hoseAllows for use in a broader range of hydraulic systems where two wire hoses may have been required in the pastAdditional protection against heat in demanding applications
- Exceeds SAE 100R1 Type S, EN857 1SC
Type | Hydraulic Hose |
Style | H180 WeatherSHIELD |
Size | 3/8" |
Material | Nitrile/WeatherSHIELD |
I.D. | .38" |
O.D. | .64" |
Color | Black |
Inner Tube | Nitrile |
Outer Cover | WeatherSHIELD |
Dash Size | -6 |
Recommended Fitting Types | “Z” series |
Burst Pressure | 13600 PSI |
Max Working Temp F | 260 |
Working Pressure | 3400 PSI |
Temp. Range | -46°C to +127°C (-50°F to +260°F) |
Certifications | EN857 1SC|ABS|SAE 100R17|SAE 100R1AT|EN853 1SN|EN853 1ST |
Compliances | DNV|MSHA Approved|USCG |
Manufacture Part # | H18006 |
Replaces Part No. | H10406 |
Pkg Qty. | 50 |
