- Dual-Element, Time-Delay Fuses are Class RK5 rated at 250 Volts
- Typically used in power panel boards, motor controllers, starters, and machinery disconnects
Type | Cartidge |
Style | Time-Delay |
Voltage | 250 VAC |
Amps | 4 |
Material | Fiber |
Element | Dual |
Length | 2" |
Dia. | .56" |
Series | FRN-R |
Industry No. | FRN-R-4 |
Indicating / Nonindicating | Nonindicating |
Class | RK5 |
Body Style | Cylindrical |
Interrupt Rating | 200kA |
Standards | CE, Std. 248-12, Class RK5,UL Listed, Guide JDDZ, File E4273, CSA Certified, Class1422-01, File 53787 |
Application | Power Panelboards, Motor Control Centers, Combination Starters, Machinery Disconnects |
