- This Digital Angle Gauge and Level can measure or set angles, check relative angles, or can be used as a digital level
- High visibility reverse contrast display improves visibility in dimly lit work environments
- Strong magnetic base to attaches to conduit, pipes, saw blades, vents, ducts, and other ferromagnetic surfaces
- V-groove edges enable optimal alignment on conduits and pipes for bending and alignment
- 0 to 90-Degree and 0 to 180-Degree measurement ranges facilitate multiple and diverse applications
- 0 to 180-Degree range is useful when accounting for kickback in pipe bending applications when bending to 90-Degree or more
- Display auto-rotates when upside-down for easy viewing
- Water and dust resistant with rating of IP42
- Soft carrying case and two AAA batteries included
| Type | Measuring Tool |
| Style | Angle & Level |
| Material | ABS Plastic Housing and Electronic Components |
| Magnet Type | Permanent Rare Earth |
| Weight | 3.5 oz (99.2 g) |
| Overall Width | 1.2 Inch (3 cm) |
| Overall Height | 2.2 Inch (5.6 cm) |
| Overall Length | 2.36 Inch (6 cm) |
| Accuracy | ¬±0.1° from 0° to 1°, 89° to 91°, 179° to 180°; ¬±0.2° at All Other Angles |
| Application | Measure or Set Angles, Check Relative Angles, or Use as a Digital Level |
| Ingress Protection | IP42: Water and Dust Resistant |
| Special Features | V-grooves Around Entire Perimeter, Dual Measurement Ranges at 0° to 90° and 0° to 180°, Reverse Contrast |
| Drop Protection | 6.6' (2 m) |
| Batteries | 2 x 1.5 AAA |
| Included | Soft Carrying Case, Instruction Manual, Batteries |
| Low Battery Indicator | Yes |
