BUSSMANN™
FB181F120
SKU FB181F120

120 AMP, 48 VDC High Amp Circuit Breaker, Type I

UPC:
39121601
Pkg Qty: 1
  • 120 Amps High Amp Circuit Breaker is good for use with battery isolators/multi-battery installations in truck, bus, RV, and marine applications
  • Type I - Automatic Reset
Type Type I Circuit Breaker
Style High Amp Flush Mount
Voltage 48 VDC
Amps 120
Material Thermoset Plastic
Length 2.89"
Width 1.90"
Terminal Type Stud
SAE Type Type I Automatic Reset
Terminal Size 1/4"-28
Mounting Surface
Mounting Hole Dia. 1/4"
Height 1.44"
Mounting Length 2.23"
Mounting Width 1.05"
Approvals Sae J1117
