MOLEX
9H2MM6
SKU 9H2MM6

2 Circuit Plug, Pin & Socket - Male .062

Pkg Qty: 10
  • Molex 0062 Style provides a reliable and economical choice for power interconnect applications
  • The 03062023 receptacle is a 2 connector housing with detent windows and is dual gender
  • Housing is without mounting ears
Type Pin & Socket
Style Plug
Color Natural
Material Nylon
Temp Range -40° C to +105° C
Circuits (maximum) 2
Circuits Detail 1x2
Mates With 03-06-1022, 03-06-1023, 03-06-6023
Number of Rows 1
Glow-Wire Compliant No
Panel Mount No
Pitch - Mating Interface 3.68mm
Pitch - Termination Interface 3.68mm
Polarized to Mating Part Yes
Stackable No
Use With Female Crimp Terminals 1561, 4559, 4529, 2190, 2189 , 1787, 1855 <BR> Male Crimp Terminals 1560, 1786, 1854<BR> 1778 Male PC Tail Terminals<BR> 1779 Female PC Tail Terminals
Style 1625
Related Receptacle 9H2FM6
Related Pins 91824MM6
