50 Amps (ANL-50), Medium-Acting Bolt-Down

Pkg Qty: 5
  • Time-delay style limiters with a bolt-on design and small footprint to save space
  • The built-in window conveniently shows limiter status
Type Bolt-Down
Style Medium-Acting
Voltage 125 Vac, 80 VDC
Amps 50
Material Fiber
Element Single
Width 7/8"
Length 3-3/16"
Series ANL
Industry No. ANL-50
Indicating / Nonindicating Nonindicating
Class Limiter
Body Style Bolt-on
Interrupt Rating 2500A @ 125 VAC — 2700A @ 80 VDC
Standards UL Recognized Guide JFHR2, File E56412; CSA Certified Class 1422-30, File 53787, CE for 35-400A.
Application Fork lifts, Marine, Aviation
