3M™
2D463
SKU 2D463

8 AWG, 3/8" Stud Size, Ring Terminal, Vinyl Insulated

UPC:
39121432
Pkg Qty: 25

  • Temperature Rating: -40°F to 221°F
  • 600 Volt Rating
  • Annealed Copper – Electro-Tin Plated
Type Vinyl Insulated
Style Ring
AWG 8
Color Red
Voltage 600 VAC, 60 VDC
Finish Tin
Insulation Nylon
Material Copper
Stud Size 3/8"
Series 2
Barrel Type Closed
Max Wire Insulation Dia. 0.34
Length 1.38
Width 0.59
Throat Length 0.45
Effective Length 1.08
Barrel I.D. 0.175
Material Thickness 0.05
Specifications UL, CSA
