Insulation Resistance Tester


California Residents: Prop 65 Warning
WARNING: Cancer and Reproductive Harm

Pkg Qty: 1
  • Voltage Tester tests insulation resistance up to 4000M‚Ѷ at 125V, 250V, 500V, and 1000V DC
  • Megohmmeter with test and lock buttons for simple insulation testing
  • Warning alarm and high voltage icon for detection of voltage
  • Measures up to 1000V AC/DC, resistance, and continuity
  • Automatic ranging True Root Mean Square (TRMS) technology for increased accuracy
  • Backlit display with bar graph, Auto-power off, High Voltage, Max/Min, and Hold icons
  • Low battery indicator with easily replaceable battery and fuse
  • Built-in stand and optional magnetic hanger for hands free operation
  • Test verification of conformity to EN61557-1,-2,-4
Type Multimeter
Style Insulation
Color Orange/Black
Functions Insulation Resistance, Voltage AC/DC, Resistance, and Continuity
Overall Length 7.93 Inch (20.2 cm)
Batteries 6 x AA
Weight 1.4 lb (0.6 kg)
Overall Height 2.32 Inch (5.9 cm)
Overall Width 3.59 Inch (9.1 cm)
Included CAT III/CAT IV Safety Rated Test Leads, Heavy-duty Alligator Clip Test Leads, Batteries, Carrying Case, and Instruction Manual
Ohms (Resistance) 4000M
Special Features Lock Button for Insulation Resistance Testing
Application Installation, Troubleshooting, and Preventive Maintenance of Electrical Wiring and Electrical Equipment, Measures 1000V AC/DC, Resistance, and Continuity
Voltage 125V, 250V, 500V, and 1000V DC; 1000V AC/DC
Standard CAT IV 600V/CAT III 1000V, EN61557-1, EN61557-2, EN61557-4
Display 4000 Count LCD
